Vacuum Drill in Bibra Lake, Western Australia, Australia
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
Description
The Vacuum drilling system, originally patented in the early 1960’s, has been specifically developed to provide a low cost, highly efficient drill sample recovery system. Extensive field development and testing has resulted in the vacuum drilling system being recognised as available accurate drilling method.
Principally designed for mineral exploration drilling, the Vacuum Drilling system has gained world wide application, with emphasis in bauxite and gold mining industries.
The system comprises vacuum pump, oil bath filter, sample separator, vacuum swivel and drive shaft adaptor to rotary drilling head.
The vacuum pump can be driven either hydraulically or mechanically from the existing drill rig power pack. Alternatively, separate independent drive source can be provided.
Continuous rating for the vacuum pump is 112 cfm at 20″ Hg vacuum.
First, sample is removed from the rod string via the vacuum swivel mounted above the rotary head.
