Woodworking Automatic Loading CNC Router Machine in Shandong, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Certification
- CE
- Cnc or not
- CNC
- Voltage
- 380V
- Spindle speed
- 24000rpm/Min
- Machining accuracy
- ±0.04mm
- Feeding size
- 1300*2500*180mm
- Spindle power
- 4.5kw
- Cutter
- 3-12.7mm
- Transport package
- Plywood Case
- Specification
- 4*8 ft or 5*10 ft
- Hs code
- 84659900
- Production capacity
- 500 Set/Year
- Category
- CNC Wood Routers in China
- Subcategory
- Woodworking machinery
- Subcategory 2
- Woodworking engraving machine
- Subcategory 3
- Manufacturing & processing machinery
- Listing ID
- 85901372
Description
Woodworking automatic loading CNC router machine
Product details:
Specification:
MJ1325 CNC ROUTER
Model
MJ1325
Range of work
1300x2500mm
Working height
200mm
Running speed
20m/min
Processing speed
10m/min.
Driving mode
450B step motor drive
Driver
Thessai 860
Spindle power
3.2kw water-cooled variable frequency spindle
XY guideway and transmission
20 linear guideway, high precision rack drive
Z axis guideway and drive
20 linear guideway, original tbi ball rod transmission
Main shaft speed
24000rpm/min
Working voltage
220v/50hz(380V/50hz)
Support format
*nc,G code,*uoo,*mmg,*plt
Tool knife diameter
¢3.175mm ¢6mm ¢12.7mm
Control system
Dimension control system
Oiling
Manual oil injection
Vac-sorb
5.5kw 380V Vacuum adsorption system (selection)
Control cabinet
Independent control cabinet (optional built-in control cabinet)
Advantage:
