Gbt16429 Minimum Ignition Temperature Tester in Chongqing, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Standard
- IEC 61241-2-1
- Application
- Measure Heat Release of Building Materials
- Bomb capacity
- 300 Ml
- Maximum power
- 0.5kw
- Furnace temperature
- Room Temperature ~ 800c
- Size
- 500X300X450 mm
- Power
- 230V / 50Hz or 110V / 60Hz.
- Transport package
- Plywood Case
- Hs code
- 9031809090
- Production capacity
- 100 Sets/Month
- Subcategory
- Analysis instrument
- Subcategory 2
- Instruments & meters
- Subcategory 3
- Analysis instruments
- Listing ID
- 81616761
Description
GBT16429 Minimum Ignition Temperature Tester
Products:
The minimum ignition temperature tester is a way of testing the sensitivity of the ignition that the dust cloud in the heated environment. When a lot of dust is exposed in heating the air and the air temperature is high enough, it may lead to spontaneous combustion. This instrument can test the minimum ignition temperature of combustible dust cloud.
Standard:
IEC 61241-2-1:1994,EN 50281-2-1:1999,
GB / T 16429 "minimum ignition temperature of a dust cloud testing methods" .
Technical parameters:
1. The tester is carried on the in Godbert-Greenwald furnace.
2. The heating furnace is consist of the vertical quartz tubes . The hole is at the bottom of the tube.
3. Furnace operating temperature range: room temperature ~ 800 ºC
4.The operating temperature can rise to 1000 ºC to clean the the test chamber .
5. Temperature accuracy: ± 1% (higher than 500 ºC), ± 3% (lower than 300 ºC).
6.
