Ozone Resistance Environmental Testing Chamber Environmental Tester Ozone Accelerate Aging Testing Chamber in Dongguan, Guangdong, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Temperature range
- 0℃～ 60℃
- Temperature fluctuation
- ±0.5℃ (At no-load)
- Temperature uniformity
- ±2℃ (At no-load)
- Humidity range
- ≤65%RH
- Ozone concentration
- Adjustable , 10－500pphm
- Ozone concentration accuracy
- ±10% pphm
- Ozone air flow velocity
- 8～16mm/s
- Test time
- 0 ～ 999 hour
- Air flow change
- 20L～80L/min
- Sample shelf
- 360° rotation
- Power
- 380V/50Hz
- Working room
- 500×400×500(D×W×H)mm
- Interior box material
- SUS304 superior stainless steel
- Outer box material
- A3 steel board with paint
- Insulation material
- Thin glass fiber insulation cotton
- Heating method
- Electrical heating tube
- Circulatory system
- Single-channel air circulation, Centrifugal wind wheel
- Temperature control
- High precision digital temperature controller(with ozone concentration test)
- Accuracy
- ±0.1℃
- Min display resolution
- 0.01℃
- Resolution
- ±0.1℃
- Electrical apparatus element
- DELIXI contactor,Omron relay
- Sensor
- Pt100 sensor
- Power supply
- Delixi(with leakage protection)
- Control method
- Continuous PID control
- Solid replay
- The US Coot(SAP4040D/4025D)
- Turntable motor
- Imported brand
- Electronic governor
- Imported brand
- Place of origin
- Guangdong, China
- Certification
- ISO 2009
- Minimum order quantity
- 1set
- Packaging details
- Non-fumigation wooden box
- Payment terms
- FOB Shenzhen, L/C, T/T, Western Union
- Supply ability
- 50 sets per month
- Interior box material-outer box material
- SUS304 Superior Stainless SteelA3 Steel Board With Paint
- Insulation material-heating method
- Thin Glass Fiber Insulation CottonElectrical Heating Tube
- Circulatory system-temperature control
- Single-channel Air Circulation, Centrifugal Wind WheelHigh Precision Digital Temperature Controller（with Ozone Concentration Test）
- Accuracy-min display resolution
- ±0.1℃0.01℃
- Resolution-electrical apparatus element
- ±0.1℃DELIXI Contactor、Omron Relay
- Highlight
- environmental testing chamber, material testing equipment
- Category
- Environmental Chambers in China
- Subcategory
- Testing equipment
- Subcategory 2
- Environmental test chamber
- Listing ID
- 64417604
Description
The tester is used for the ozone-resistance test of the rubber and rubber products
The ozone aging test chamber is applicable to the rubber products like vulcanized rubber and thermoplastic rubber, cable insulation sheath, etc. Exposed to the closed dark environment with constant ozone concentration and temperature, the sample is stretched statically or dynamically or alternately. After the preset testing time, check the rubber or rubber products for any fracture or other changes. Then evaluate the ozone-resistance performance of the sample and take effective measures to increase the sample lifetime.
Fix the sample in the special fixture, and then choose one elongation rate for the sample (generally 20%). The fixture is installed on the rotational sample shelf with the speed of (20~25)mm/s. The test temperature is(40±2)℃ and the relative humidity is less than 65%.
JIS K 6259,ASTM1149, ISO1431, GB/T7762,GB/T13642-92
