MDI Advanced Processing GmbH laser cutting machine LC 800 in Borken, North Rhine-Westphalia, Germany
Used
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- used
- Stock number
- 19834
- Content
- 1 piece
- Mass
- 3,500,000 g
- Category
- Glass equipment in Germany
- Subcategory
- Laser technology
- Listing ID
- 42051088
Description
MDI
Type: LC 800 laser cutting system
MDI laser cutting system
LC 800 laser cutting system with UC-2000 laser controller and
MSA control system 9010 LCD for gas warning system
Technical data:
Machine data:
Machine dimensions: (L x W x H) 2,520 mm x 2,090 mm x max. 1,945 mm
Control cabinet dimensions: (W x D x H) 600 mm x 600 mm x 2,000 mm
Machine weight: approx. 2,500 kg
Mass of switch cabinet: Approx. 1,000 kg
Control system: Siemens S7-300 and Siemens Simotion
Spindle drives: THK
Rotation axis: Harmonic Drive
Table size: 810 mm x 680 mm
Max. Substrate size: 650 mm x 780 mm
Number of cutting heads: 2 (laser for glass cutting, knife for foil cutting)
Number of cutting tables: 1
Workpiece clamping: Laser cut frame for laser cutting, vacuum plate for foil cutting
Noise level: <75 dB(A)
Connection data:
Electrical connection: 3x 400 V AC NPE, 50 Hz
Connected load: 9 kVA
Control voltage: 24 V
Main fuse: NH 00 35 A
Compressed air: 6 bar (± 0.5 bar)
Vacuum flow: 3.6 mm³/s
Cooling: Water-ethanol-air mixture
$15,174 USD
