Extech EX810 in Cary, NC, USA
Used
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
Description
AC Clamp Meter, 1000A with IR Thermometer Key Features & Specifications Extech EX810: 1000A AC Clamp Meter with IR Thermometer Non-contact InfraRed Temperature measurements with laser pointer Peak hold captures inrush currents and Transients MultiMeter functions include AC/DC Voltage, AC Current, Resistance, Capacitance, Frequency, Diode, and Continuity 1.7"" (43mm) jaw opening for conductors up to 750MCM or two 500MCM 4000 count backlit display Autoranging with manual range button Features include Data Hold and Min/Max, Auto Power off Complete with test leads, 9V battery and case Specifications IR Temperature (IR) -58 to 518ºF (-50 to 270ºC) ±2.0% rdg or ±4ºF/±2ºC AC Current 0.1 to 1000A ±2.8% AC Voltage 0.1mV to 600V ±1.8% DC Voltage 0.1mV to 600V ±1.5% Resistance 0.1 to 40MΩ ±1.5% Capacitance 0.001nF to 40,000μF ±3.0% Frequency 0.001kHz to 4kHz ±1.5% Continuity Yes Inrush Yes Diode Yes Dimensions 0.6x4.3x2"" (270x110x50mm) Weight 13.
