SmartScope ZIP 250 Compact Benchtop Multisensor Metrology System Smart Scope CMM Measuring Machine in Central Falls, RI, USA

Accurate video metrology – AccuCentric® motorized zoom lens automatically compensates magnification for each zoom position

Reliable & Precise – Heavy-duty cast base and integral compound stage with Y-axis center drive for stability

Multisensor versatility – Optional touch probes, lasers and micro-probes

ZIP 250 Travel mm / inch

X axis... 250mm... 10"

Y axis ...150mm... 6"

Z axis ...150mm... 6"

- 110V
- Serial # SK 2252183

Standard AccuCentric® auto-compensating zoom, motorized; 1.0x lens; 2.0x lens attachment; 1.0x adapter tube

Optional Focus Grid Projector: LED or Tungsten fiber-optic sources

Laser Adapter: Allows for field retrofit of TTL laser. Included Laser Pointer

Replacement Lenses: 1.0x Long Working Distance (LWD), 2.5x, 5.0x

Laser Lenses: 2.0x (included with TTL Laser), 5.0x

Lens Attachment for 1.0x Lens: 0.5x, 0.75x, 1.5x

Factory Installed Adapter Tubes: 0.67x, 2.0x

Illumination

Standard Substage LED profile, coaxial LED surface, SmartRing LED ring light (white)

Optional Coax Light: Tungsten Fiber-Optic

Ring Lights: Red, Green, or Blue SmartRing; Standard or Low Incidence VuLight; Tungsten Fiber-Optic Ring mounted below, integrated with, or in lieu of SmartRing

WSPT# LRQ-0000-052225-B

R080425

Picture# File

* All information deemed accurate but may vary from model to model.
