Draw Tape Bag Making Machine Drawstring Bag Making Machine Not Roll in Jiangsu, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Product line
- 1
- Shipping cost
- Contact the supplier about freight and estimated delivery time.
- Secure payments
- Every payment you make on is protected by the platform.
- Refund policy
- Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
- Lines
- 1
- Voltage
- 220V/380V
- Seals mode
- Hot Seal
- Speed
- High
- Continuous-rolled
- No
- Sealing & cutting
- Heat-Sealing Cold-Cutting
- Layer
- Double
- Machine type
- Bag Forming Machine
- Computerized
- Computerized
- Motor brand
- Made in Taiwan
- Servo motor
- Made in Taiwan
- Temperature controller
- Made in Taiwan
- Material
- HDPE,LDPE
- Machine control
- Computer Box
- Loading
- Two Air Cylinders
- Bag making methods
- Piece by Piece
- Optional equipment
- EPC
- After-sale service provided
- Engineers Available to Service Machinery Overseas
- Transport package
- Wrapping Film Packing or Packed in Wooden Case
- Specification
- CE, ISO9001: 2008, SGS, TUV
- Hs code
- 84778000
- Subcategory
- Bag making machine
- Subcategory 2
- Packaging & printing
- Subcategory 3
- Plastic bag making machine
- Subcategory 4
- Machinery for packaging supplies
- Listing ID
- 103638372
Description
Parameters:
Model
GBBCR-1200
Bag making speed
20-70 pcs/minute
Max line speed of film
60 m/min
Bag making length
100-1000mm
Bag making width
300-1000mm
Bag making thickness
0.02-0.15mm
Kind of bag making
Printing bag and white bag
Bag making methods
Pcs by pcs draw tape bag or pcs by pcs flat bag
Machine main controller
Computer controller
Total power of machine
10kw
Feeding motor
3kw Servo motor
conveyer belt
With
Features:
1. The machine is specialized in the production of HDPE, LDPE, drawstring bag on roll, and flat garbage bag on roll.
2. Control by PLC and touch screen.
3. Servo (step) motor control speed and bag length.
4. With functions such as photocell automatic tracking, blank/color bag-making shift, microcomputer length setting, automatic counting, automatic alarm when reach number, automatic temperature control, loading film and discharge finish roller by air cylinder.
5.
