S100 10 PCS Linear Tool Change CNC Router Machine CNC Drilling Machine High Precision High Speed CNC Cutting Machine in Anhui, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Certification
- ISO, CE, Ce, ISO 9001, Patent Certification
- Cnc or not
- CNC
- Voltage
- 380V
- Process usage
- CNC Non-Conventional Machine Tools
- Movement method
- Contour Control
- Control method
- Closed-Loop Control
- Numerical control
- CNC
- Processing precision
- 0.01~0.02(mm)
- Performance classification
- MID-Range CNC Machine Tools
- Application
- Wood, Bamboo, Marble, Organic Board, Color Plates
- Configuration
- 9kw Air Cooling Spindle + Linear Tool Change
- Transport package
- Wrapped in Layers of Wrapping Film and Ponchos
- Specification
- Working Area: 1230*2450*200mm
- Hs code
- 8465990000
- Production capacity
- 3000 Sets/Year
- X/y/z axis working stroke
- 1300*2500*300mm
- Table surface
- vacuum Table
- Spindle power
- 9KW Italy HSD ATC air cooling spindle
- Spindle speed
- 0-24000 rpm
- Automaitc tool change
- Straight, 8pcs
- Control system
- Taiwan Syntec 4 axis control System
- Drive sytem
- Japan Yaskawa servo motor & driver
- Transmission
- X/Y axis helical rack & pinion, Z axis ball screw
- Guide rail
- Taiwan imported linear guide rail
- Vacuum pump
- 7.5kw vacuum pump
- Inverter
- Fuling or Zoncn
- Oil lubrication
- Automatic
- Positioning accuracy
- ± 0.03mm
- Subcategory
- Woodworking machinery
- Subcategory 2
- Woodworking engraving machine
- Subcategory 3
- Manufacturing & processing machinery
- Listing ID
- 103571520
Description
Good Price CNC Router Automatic 10 PCS Linear Tool Change China
Keywords:15 years experience of production
ISO9001:2008, CE, SGS, AAA Level Enterprise which Honors Contract
Three Brand: Mars, Golden Eagle,Borio
Good Price CNC Router Automatic 10 PCS Linear Tool Change China is MARS featured machine for processing molded doors, wooden windows, wooden cabinet, wood panels. MARS designs it for many years, now popular in the market, it's economic machining center of woodworking cutting machine.
Functions:
The functions of this machine include cutting,milling,drilling and slotting.
Applicable Materials:
MDF, block board, solid wood board, particleboard, polymer door plates, plywood etc.
Application Scope:
Cabinet doors, wooden doors, solid wood, panels, doors, windows, tables, chairs, folding screens, waved plate, large wall hangings, advertising boards, sign makings.
Parameters:
Model, Simple and Easy S100 Atc Linear Tool Change Engraving Machine
$17,688 USD
