2024 Hot Sale High Output Conical Twin Screw Extrusion Machine PVC Plastic Products Extruder Pipe Profile extrusion in Jiangsu, China
Used
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- used
- Plastic processed
- PVC
- Application
- PIPE
- Screw design
- Double-screw
- Twin screw type
- Counter-rotating conical Twin-screw
- Screw material
- 38CrMoALA
- Screw diameter (mm)
- 80/156
- Screw l/d ratio
- Unapplicable
- Screw speed (rpm)
- 34.7
- Place of origin
- Zhangjiagang Jiangsu China
- Voltage
- 220V/380V/415V/440V
- Dimension(l*w*h)
- 4.7*1.5*2.4m
- Power (kw)
- 55
- Key selling points
- Multifunctional
- Video outgoing-inspection
- Provided
- Core components
- motor PLC Engine Gearbox Screw
- Machinery test report
- Provided
- Weight (kg)
- 5000
- Extruder type
- twin screw
- Name
- double-screw plastic extruder
- Product type
- pvc plastic pipe profiled material
- Central height
- 1100mm
- Output (kg/h)
- 400
- Category
- Extruders in China
- Subcategory
- Plastic extruders
- Subcategory 2
- Industrial machinery
- Subcategory 3
- Plastic & rubber processing machinery
- Listing ID
- 101846146
Description
Conical twin screw extruder ,
specially designed for the PVC powder extruding,
it can be equipped in
PVC pipe production line,
PVC profile production line,
WPC profiles production line,
also used for PVC hot die face granulating line.
PVC Conical twin screw extruder ' screw structure also can re-designed according to customer's detail raw material and the purposes.
we can produce many of different models extruders,
such as SJSZ45/90; 45/100; 48; 50/105(also can be said 51/105); 55/120(or 55/110); 65/132; 80/156; 92/188;110/220.
or also can according to customer's required design.
there are horizontal type gearbox, integral vertical type gearbox.
Here I take one of our
SJSZ80/156 Conical twin screw extruder
with normal vertical gearbox for example:
Screw and barrel
80/156 conical twin screw barrel
conical twin screw barrel
Gearbox
JC hard gearbox,vertical,SZ80
vertical 80/156 gearbox
vacuum pump
venting
Driving motor
driving motor of 80/156 extruder,SIEMENS /BEIDE
$29,500 USD
