2013 Studer S41 in Chicago, IL, USA
Used
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- used
- Year
- 2013
- Machine type
- Grinders
- Machine location
- Upon Request
- Stock #
- 932681
- Distance between centers
- 1600mm (63″)
- Center height
- 225mm (8.86″)
- Weight between centers
- 250kg (551 lbs)
- Strokes (z/x)
- 1.750 x 350mm (68.9″ x 13.78″)
- Feeds max. (z/x)
- 20.000 mm/min (787 ipm)
- Stroke b-axis
- -45° / +225°
- Indexing precision b-axis
- 0,001°
- Wheel dimensions (ø x width x bore) t1
- 500 x 80 x 203 mm (19.69″x3.15″x7.99″)
- Wheel dimensions (ø x width x bore) t2
- 500 x 80 x 203 mm (19.69″x3.15″x7.99″)
- Motor power
- 15 kW (20 hp)
- Wheel speeds
- 750 – 4.500 rpm
- Type of cone
- MT4
- Speeds
- 1 – 1.500 rpm
- Power
- 10 kW (13 hp)
- Quill stroke
- 80mm (3.15″)
- Floor space
- 5.200 x 3.800 mm (204.7″x149.6″)
- Height
- 2.107 mm (82.96″)
- – weight
- 10.200 kg (22.487 lbs)
- Voltage
- 400 V
- Frequence
- 50 Hz
- Installed power
- 30 kVA
- Category
- Grinding machines in USA
- Subcategory
- Cnc
- Subcategory 2
- Grinders
- Listing ID
- 101438002
$299,500 USD
